Projects Route and 3D Scene Architecture

Goal#

The projects route is designed to feel like a showcase, not just a list of links.

Main goals:

• combine project details with a 3D hero area
• make the laptop model feel polished
• keep the layout responsive
• keep interaction controlled

Route structure#

The route is built around two main blocks:

• project info card
• 3D canvas card

This is the basic idea:

<ProjectInfoCard />
<ProjectScene />

The card explains the project. The canvas gives the route its visual identity.

3D stack#

The scene uses:

• React Three Fiber
• Drei
• Three.js
• postprocessing

Key scene pieces:

<Canvas>
  <Environment />
  <Float>
    <DemoComputer />
  </Float>
  <ContactShadows />
  <OrbitControls />
</Canvas>

This keeps the scene modular and easy to tune.

Lighting approach#

The model uses layered lighting instead of one generic source.

Used lights:

• ambient light
• spotlight
• directional light
• rim point lights
• backlight

Example:

<ambientLight intensity={0.06} />
<spotLight position={[6, 5, 3]} intensity={48} />
<directionalLight position={[-5, 3.5, 2.5]} intensity={1.6} />

Why:

• better shape definition
• stronger product feel
• more controlled highlights

Post-processing#

The route uses subtle post-processing for polish:

• bloom
• contrast tuning
• saturation
• chromatic aberration
• vignette

Example:

<EffectComposer>
  <Bloom intensity={0.45} />
  <BrightnessContrast brightness={0.02} contrast={0.12} />
  <Vignette darkness={0.65} />
</EffectComposer>

The values stay restrained so the model still feels clean.

Model rig and responsiveness#

The laptop model is wrapped in a rig that changes based on screen width.

const isSmallScreen = size.width < 650;

<group
  scale={isSmallScreen ? 1.05 : 1.42}
  position={[0, isSmallScreen ? -1.34 : -1.52, 0]}
>
  <DemoComputer />
</group>

This is important because a model that looks good on desktop can easily break composition on smaller devices.

Project card system#

The text card handles:

• project title
• bullet points
• featured badge
• tags
• live/repo actions
• previous/next controls

The project data is stored centrally and rendered from state.

const [selectedProjectIndex, setSelectedProjectIndex] = useState(0);
const currentProject = myProjects[selectedProjectIndex];

That makes the route easier to update without rewriting UI logic.

Short architecture summary#

The projects route is:

• one responsive 2-column showcase
• one controlled 3D scene
• one state-driven project card system
• one shared visual language using global tokens

Prompt#

If you want to build a projects route like this, use this prompt:

Build a projects showcase page in Next.js with React Three Fiber.
Use a 2-column layout with a project information card and a 3D laptop scene.
Use layered lighting, soft post-processing, and a responsive model rig.
Keep controls constrained so the scene stays elegant.
Render project content from centralized data with title, points, tags, repo link, and live link.
Make the route feel premium but still responsive on small screens.
